CH Precision P1 Phono-Stage
,

CH Precision P1 Phono-Stage

CH Precision P1 Reference Phono-Stage.

It is well known that the electrical characteristics of turntable cartridges differ greatly from one cartridge to another. Ohm’s law shows that Moving Magnet cartridges will generate larger voltages while Moving Coil cartridges are generally more efficient at delivering current. Phono stages should take full advantage of the cartridges’ strengths and amplify the signal in the way they work best.

With two dedicated MC current inputs and one MM/MC voltage input, the P1 provides the optimal coupling to all types of cartridges.

In addition, discrete class A stages as well as the highest grade, tight tolerance components allow the P1 to deliver high performances for a transparent yet natural sound.

Manufacturer’s website CH Precision

SKU: 91009 Categories: , Tags: , , , , ,

CH Precision P1 Phono Preamplifier Features and Specifications

Modularity

Two P1 configurations are available:

  • Dual Monaural (two channels in a single enclosure)
  • True Monaural (each channel in its own enclosure)
Moving coil current inputs

The P1 provides two moving coil current inputs, featuring the following specifications:

  • inputs specifically designed for low output, low internal resistance MC cartridges
  • current mode for best signal to noise ratio when paired with low output MC cartridges
  • no impedance adjustment required in current mode
  • XLR and RCA connector available on each input
Moving magnet / moving coil voltage input

The P1 provides a more classical voltage input, featuring the following specifications:

  • input designed for MM, MC cartridges and step-up transformers
  • ultra low noise FET-input stage
  • cartridge loading adjustment, variable from 100k Ohms to 20 Ohms in over 500 steps
  • wizard to select the cartridge’s optimal loading through frequency response automated analysis
  • XLR and RCA connections
EQ curves
  • RIAA and enhanced RIAA (with additionnal Neumann pole) EQ curves factory fitted
  • high grade, tight tolerance custom components
  • optional add-on board containing EMI, Columbia, Decca and Teldec EQ curves
Analog signal path
  • selectable high-pass subsonic filter to remove unwanted rumble
  • ultra low noise, high bandwidth, high slew rate design
  • class A, discrete transistor based design
Power supply
  • ultra low noise, high accuracy, discretely regulated linear power supplies
  • oversized mains toroidal transformers
  • shunt regulators for all stages
  • can be powered from the X1 External Power Supply unit
MC current inputs
Input type2x current mode inputs, XLR and RCA connectors available
Input impedance<100mΩ, virtual ground inputs
Gain6 steps (gain dependent on the cartridge internal resistance)
Equivalent input noise (EIN)<-135dBu without X1 unit / <-138dBu with X1 unit / 1Ω termination, gain +70dB, 22kHz BW

MM/MC voltage input

Inputs type1x voltage mode inputs, XLR and RCA connectors available
Input impedanceVariable from 100kΩ to 20Ω
Gain (at 1kHz)+35dB, +40dB, +55dB, +60dB, +65dB, +70dB
Equivalent input noise (EIN)<-130dBu without X1 unit / <-135dBu with X1 unit / 1Ω termination, gain +70dB, 22kHz BW
Analog outputs
Output levelUp to 8V RMS (balanced), Up to 4V RMS (unbalanced)
Frequency response> 400kHz (RIAA equalization filter disconnected), current input selected
Total Harmonic Distortion + Noise<0.01%, 1kHz, output level 3V RMS, 22kHz BW
General
Display480×272 pixels, 24bits color, AMOLED
Mains operationSelectable 100V, 115, 230V AC, 47-63Hz
Power supply consumption<1W (standby), 100W max in operation
Dimensions/Weight440 x 440 x 133mm (W x D x H), 20kg
Remote controlEthernet based system control via the Android CH Control App

Please find review below

http://www.ch-precision.com/advert/reviews

CH Precision P1 Phono Stage review by Michael Fremer in “Stereophile” Magazine, February 2023
Complete review at https://www.stereophile.com/content/analog-corner-260-ch-precision-p1-phono-preamplifier

PT.2 by Michael Trei, July 2023 – https://www.stereophile.com/content/spin-doctor-2-ch-precision-p1-phono-preamplifier

Image result for the audio beat logo

CH PRECISION P1 Monural PhonoStage Review in ” The Audio Beat “ Magazine, March 2020

http://www.theaudiobeat.com/blog/ch_precision_p1_mono.htm

CH PRECISION P1 and X1 Phono Stage and Power Supply review ” The Absolute Sound ” Magazine, August 2019

http://www.theabsolutesound.com/articles/ch-precision-p1-phonostage-and-x1-power-supply/

Image result for hifi advice.com logo

CH PRECISION P1 Phono-Stage review by ” HiFi Advice ” Online Magazine, August 2019

Image result for mono stereo logo

CH PRECISION P1 Phono-Stage Review in ” Mono & Stereo ” Magazine, February 2019 EDITORS CHOICE AWARD!

https://www.monoandstereo.com/2019/02/ch-precision-p1-phono-preamplifier.html

Image result for the audio beat logo

CH Precision P1, L1 and M1 Review by Roy Gregory in ” The Audio Beat “ Magazine, May 2018

http://www.theaudiobeat.com/equipment/ch_precision_l1_p1_m1.htm

CH PRECISION & WILSON BENESCH System review by ” HiFi Plus ” Magazine Issue 159 , May 2018

Complete review HERE

Image result for stereophile logo

CH PRECISION P1 Phono Stage Review by Michael Fremer ” STEREOPHILE “ Magazine, April 2017
Complete review HERE

Image result for positive feedback audio

CH Precision P1 Phono-stage review by ” Positive Feedback ” Online Magazine, January 2017

http://positive-feedback.com/reviews/hardware-reviews/ch-precision-p1-phono-stage/


Weight30 kg
