Bel Canto C6i Specifications
Amplifier Section: | |
| Power Output 1% THD: | 125W per channel |
| Minimum Load: | 2 ohms per channel |
| Peak Output Current: | 12.5 amperes |
| Frequency Response: | +/-3 dB 1.5Hz-90KHz |
| THD+N: | 0.003% 1W, 1KHz, 4 ohms |
| IMD (CCIF): | 0.0003%, 1W, 14:15KHz, 4 ohms |
| Output Noise: | <30uVRMS A-weighted 10Hz-20KHz |
| Damping factor: | >400 |
| Output Impedance at 100Hz: | <20 milliohms |
| Dynamic Range: | 120dB |
Digital Inputs: | |
| Maximum Data Input Rate | |
| 24bit Data at 192KS/s: | SPDIF RCA x2, TOSLINK x2, USB |
Analog Inputs: | |
| Line in impedance: | 47 Kohms, 2Vrms max |
| Phono in impedance: | 47 Kohms//150pF |
| Phono accuracy: | +/-0.25dB, 50Hz-15kHz |
General: | |
| Output connections: | 2-sets of WBT NextGen Binding Posts, RCA Line Out, Headphone Output |
| Headphone Output Current and Voltage Level: | 100mA peak |
| Line Out Impedance: | 500 ohms |
| Power On usage: | 14W |
| Power Off usage: | 0.0W |
| Internally Set Operating Voltages: | 100-120VAC or 230-240VAC 50/60 Hz |
| Size: | 8.5 x 3.5 x 12?, 216 x 88 x 305mm (W x H x D) |
| Weight: | 13lbs, 6.5Kg |
Please find reviews below:
“Twittering Machines” Online Review
Review: Bel Canto e.One C6i DAC Integrated Amplifier & e.One Stream2 Network Bridge
