ORACLE AUDIO CD 2000 MKIII / CD 2500 MKVI

Many of the problems that affect the accurate reproduction of recorded music derive from unwanted internal or external vibration. To address this issue the CD 2000 MkIII and CD 2500 Mk IV use a massive aluminum floating chassis and a Delrin decoupling system of the cd drive. Furthermore, our unique suspension and disc clamping systems originally used in our analog turntables, have been adapted for use in our “State of the Art” CD Players.

       The CD 2500 Mk IV harbors a new DAC board that uses the BurrBrown PCM1792 wich allows input and output of digital data of up to 24bits/192khz. The CD player uses four independant and fully discrete analog modules, one for each of the analog signals from the PCM1792. These analog modules wich have been further improoved from previous versions are at the center of the music reproduction quality. The CD 2500 Mk IV can be used as your reference DAC for other digital sources since it features a SPDIF digital signal input. Both the CD 2000 MkIII and CD 2500 Mk IV have had their power supply stage totally redesigned. There is better realism, more dynamics and we are closer to a true analog-like sound than ever!

Manufacturer’s Website ORACLE AUDIO


SKU: 000539 Categories: , ,

ORACLE AUDIO CD 2000 MKIII / CD 2500 MKVI Specifications

Configuration:

Solid State Chassis Brushed Aluminum with a Clear Lacquer Coating

CD Laser Mechanism:  Philips CD PRO 2LF

CD 2000 Mk III Output Interface:

BNC SP/DIF Digital Audio Signal, XLR, AES/EBU, ST (AT&T) Optical Audio Signal

Single Ended SP/DIF, Digital Audio Signal Format: BNC

Load Impedance: 75 Ohms

Output Impedance: 75 Ohms

Output Level: 0.5 Volts, peak to peak @ 75 Ohms

AES/EBU Digital Audio Signal

Format: XLR

Load Impedance: 110 Ohms

Output Impedance: 110 Ohms

Output Level: 4 Volts, peak to peak @ 110 Ohms

Toslink Optical Audio Signal Nominal Wavelength: 650nm

CD 2500 Mk IV Input / Output Interface:

Analog output : 1 Pair RCA, 1 pair XLR Balanced

RCA SP/DIF Digital Audio Signal Digital output : RCA, SP/DIF

Load Impedance: 75 Ohms

Output Impedance: 75 Ohms

Output Level: 0.5 Volts, peak to peak @ 75 Ohms

Output Impedance: Lower than 100 Ohms

Analog Output Level: 2.8 volts RMS

DAC : Burr Brown PCM1792-AG Resolution: 24bit – 192KHz

Signal to noise ratio: 129 dB

Dynamic Range: 123 dB

Total harmonic Distorsion: 0,0015%

Analog modules frequency response : 10 – 50KHz +/-0,3dB RCA

Digital Input : Plays any high resolution audio format, including 24/192 WAV native files and any PCM studio master with no compression or downgrade resolution to let them work.

Power Consumption:

CD 2000 Mk III Transport: 13W

CD 2500 Mk IV Player: 21W

Power Supply Transformer 800VA AC

Power Requirements 100 / 117 / 220 (230) / 240V, 50Hz or 60Hz

Removable Power Cord Included

Remote Control Included

Outboard Power Supply Included

Overall Dimensions (WHD) 425 x 150 x 363 mm, ( 17 x 6 X 14.5 inches ) weight 16 kilograms / 35,2 pounds

Please find reviews below
